Fiberinthebox 10Gbps OEO Series are XFP-XFP or SFP+ to XFP or SFP+ to SFP+ Optical-Electrical-Optical type media conve er / repeater for connection between fiber to fiber 10Gbps equipment function as fiber mode conve er, or as fiber repeater for long distance transmission.
It's main applications are such as connection between fiber to fiber or fiber to copper 10Gbps equipment function as fiber mode conve er, or as fiber repeater for long distance transmission or OEO for network backbone(SAN, LAN, MAN).
It suppo SDH/SONET STM-64/OC-192, 10G fiber channel, 10G Ethernet etc and can be applied in Telecommunication room, R&D laboratory, Data center or even 1310nm /1550nm/CWDM/DWDM Optical Wavelength Conversion.
Attention: This item is card type, SFP+ to/from XFP po . It could be inse ed into our 2U Multi-services unified platform Managed Chassis
Features
| 3R Repeater | Suppo Jumbo Frame |
| Transparent Transpo and very low delay | Suppo ITUT prescribed DWDM/CWDM wavelength |
| Suppo DMI function for SFP+/XFP fiber module | Suppo PRBS31 Pattern Generator and Checker function |
| Suppo Loopback test function | Economic In-band Management function |
| Powerful Network Management function (Web, SNMP, Console) -used with AN-CH10 chassis | Suppo hot plugging |
| Suppo 2U Rack (16 slots) and standalone use | Full State Led display |
| Easy installation |
Specifications
| Performance Data: Technical Indexes | Equipment function: 3R Repeater / Extender / Media conve er |
| Transmission Speed: 10Gb/s (9.95Gb/s-11.35Gb/s) | Protocols: IEEE802.3ae (10Gbase-R/LRM) |
| Access Type: 10G LAN/ 10G WAN | |
| Interface Type: | |
| A Type: SFP+ To/From SFP+ | B Type: SFP+ To/From XFP |
| C Type: XFP To/From XFP | |
| Transmission Distance: | |
| SFP+ module/ XFP module: it depends on the transmission distance of the module | |
| Maximum Packet Forwarding Rate: 14,880,950/S | |
| Network management information: Card type information | |
| SFP+ or XFP fiber module detection | SFP+ or XFP fiber module DMI function (Temperature, Voltage, Optical power) |
| Link status detector | Enable/Disabled Loopback test function |
| Enable/Disable PRBS Generator and checker function | Rate select (10Gbase-Lan or Wan) |
| Remote card's status monitor (only in pairs) | Card type information |
| Power requirement: | |
| Rack-mountable: AC 85~220V OR DC -48V | Standalone: AC 220V OR -48V |
| Power consumption: ≤4W | |
| Work Environment: | |
| Operating Temp: 0~ 50 ? | Storage Temp: -10~ 70 ? |
| Humidity: 5%~90% (non-condensing) | |
| Dimension: | |
| Card: 11.5mm (W) × 78mm (D) | Standalone: 156mm (W) × 128mm (D) × 32mm (H) |
