1X32 PLC Splitter Cassette Type SPCC Fiber Distribution Box
FS-DB-0132B terminal box as distribution box usually applicable in FTTH project, it is suitable for corridor,basement,room and building's outer walls application.With the function of mechanical splice,fusion splice,light splitting,wiring distributions.
Note: This price without 1x32 PLC Splitter
Features
Suppo branch connection styles. Suitable for multi optical fiber cable access as well. High quality water proof lock,wall mounted cabinet. Suitable for 72 pcs of SC,FC,ST adapters,easy to installation adn maintenance.High quality cold rolled steel body,electrostatic spraying with water proof powder.With access to 2 pcs of 12 cores optical fiber cables and up to 64 pcs of customer cables.Operating temperature:-30°C~+55°C; Storage temperature: -40°C~+60°C.
Dimension and Capacity
|
Item
|
FS-DB-0132B
|
FS-DB-0164B
|
|
Dimension( L×W×H )
|
450x350x150
|
600x57x*190
|
|
Cable Diameter(mm)
|
Ф10～Ф14
|
Ф10～Ф14
|
|
Cable Po s
|
2 holes
|
2 holes
|
|
Max. capacity of Splice Tray
|
12 (single fiber)
|
24 (single fiber)
|
|
Max. quantity of Splice Tray
|
3
|
3
|
|
Max. Capacity of main backbone cable
|
12 (single fiber)
|
12 (single fiber)
|
Sample Pictures
