The SMA-905 optical fiber patch cord, also known as FSMA connector, was one of the First optical fiber interconnect system that gained industry wide acceptance.SMA905 fiber patch cords make use of threaded connections and is still widely used for military, industrial, medical and Surgical applications and laser systems because of their low cost multimode coupling. It features simple termination and Assembly, and is TIA and IEC compliant. SMA 905 multimode connectors are available with stainless alloy or stainless steel ferrules.
Specifications
|
The numerical ape ure of the Qua z fiber： |
0.22-0.37 |
|||||||
|
Fiber Diameter(mm) |
0.2 |
0.3 |
0.4 |
0.5 |
0.6 |
0.65 |
0.8 |
|
|
Minimum Bending Radius |
10D (D：optical fiber core diameter) |
|||||||
|
Fiber Cor(coating layer): |
1：1.05 or 1：1.4 |
|||||||
|
Numerical Ape ure |
0.21-0.37 |
|||||||
|
Transmission(%/m0)
|
Transmission(0.20-0.4um) |
85-98 |
||||||
|
Visible Light(0.4-0.7um) |
97-99 |
|||||||
|
Near-Infrared(0.76-1.6um) |
90-99 |
|||||||
|
Heliun-Neon(0.6328um) |
99 |
|||||||
|
YAG(1.06um) |
98 |
|||||||
|
Argon(0.5145um) |
98 |
|||||||
|
Transmission Power |
>130w(fibre core0.5@1.06um) |
|||||||
Make to Order
|
Connector Type |
Inner Hole Size |
Concentricity |
Roundness |
Core Material |
|
Metal Ferrule Zirconia Ferrule |
0.127~1.200mm |
≤3.0μm |
≤2.0μm |
stainless steel cupronickel |
Notes:
1 The default ferrule of the connector is Metal Ferrule,please post a inquiry for Zirconia Ferrule.
2 The common size standard of Inner Hole is 127+3/-0μm,please kindly enquiry us for other size standards.
|
Connector Type |
Tailstock of Connector |
Bare fiber clamp |
Ferrule Inside Diameter |
Concentricity |
RoundnEss |
Core Material |
length |
|
|
Metal Ferrule |
With groove |
Standard (Default) |
With |
127-2000 um |
≤5um |
≤2um |
stainless steel |
1m, 2m... custom |
|
Without groove (Default) |
||||||||
|
Zirconia Ferrule
|
Lengthen (custom) |
Without (Default) |
cupronickel |
|||||
.jpg)
HPSMA905 connector with extended tailstock
Sample Pictures
.jpg)
.jpg)
