Single E1 optical transmission equipment can be used as the local network relay transmission device, especially for a mobile communication network base station transmission optical terminal equipment and rental equipment. The devices are small, light weight and compact structure, convenient installation and maintenance; transmission quality, reliable operation.The product is an electrical interface with the PBX E1 or E1 router connected to the device, optical interface for multimode and singlemode work environment. MODEM V.35 fiber can be used in pairs, can also be achieved (Ethernet Bridge) ----- (E1 Optical Modem) ----- (Ethernet Optical Modem) network structure. Apply different fiber link transmission band management channel, you can transfer data from the same fiber-optic lines for local and remote equipment monitoring and control, and interfere with each other; provide SNMP network management.
Features:
- For a single E1 signal transmission distance is greater than 1500 m of the network environment
- Through 850nm multimode fiber network can be extended to more than 2km
- 1310nm single-mode fiber can pass to more than 20km
- Using large-scale chips, simple circuit, low power consumption, high reliability
- Provide an E1 interfaces
- Has a complete alarm and status indication function
- Accommodate multiple power environment-48VDC or 220VAC
Specifications:
- Transmit Power:-8dBm ~-15dBm
- Receiver sensitivity: ≥-36dBm
- Optical interface: SC, FC-type optional
- Optical pattern: 1B1H
- Optical modules: single fiber or dual fiber optional
- Applicable fiber: single mode or multimode fiber 1310nm optional
- Transmission distance: Normal 40km (fa hest reach 120km)
E1 po
- Nominal rate: 2048Kbit / s, tolerance ± 50ppm
- Line code: HDB3;Interface impedance: 75Ω (unbalanced) 120Ω (balance)
- Interface Type: BNC head, RJ45 crystal head
- 2048Kbit / s Digital Interface Electrical Characteristics: Conforms to ITU-T G.703 recommendation
- Jitter transfer characteristic: comply with ITU-T G.823 recommendation
- Input Jitter Tolerance: Conforms to ITU-T G.823 recommendation
- Output jitter: According to ITU-T G.823 recommendation
Working environment:
- Operating temperature: 0 ℃ ~ 50 ℃
- Storage temperature: -40 ℃ ~ 70 ℃
- Relative Humidity: 5% ~ 95% non-condensing
- Atmospheric pressure: 86 ~ 106Kpa
Power supply :
- Voltage: AC AC220V AC180V ~ 240V
- DC-DC-48V DC-36V ~-72V
- Consumption: ≤ 5W
- Dimensions: Internal power supply: 200mm × 130mm × 35mm
