0.5um White Polishing Paper
Polishing films are polishing materials with ultra-precision flexibility. They are made with diamond powders evenly coated on the surface of flexible substrate by adhesives and are often used for lapping and precision polishing of optical fiber pins, semiconducting materials, metal rollers, etc.
Features:
Evenly-sprayed pa icles on coated surfaces. Submicron powder pa icles make high polishing accuracy. Positioned lapping & polishing to save abrasive materials. Fine curved surface polishing effects because of flexible substrate. Suitable for polishing with dry, water or oil.
Specifications:
Main Specifications of Diamond Polishing Films
|
UND0.5 |
UND1 |
UND2 |
UND3 |
UND6 |
UND9 |
UND15 |
UND30 |
UND45 |
||
|
Size( μ m) |
0.5 |
1 |
2 |
3 |
6 |
9 |
15 |
30 |
45 |
|
|
Mesh |
10000 |
8000 |
6000 |
4000 |
3000 |
2000 |
1200 |
600 |
400 |
|
|
Round Specification(mm) |
Φ 70 / Φ 110 / Φ 127 / Φ 203 |
|||||||||
|
Square Specification(mm) |
114 × 114 / 152 × 152 / 228 × 228 |
|||||||||
|
Banding(mm) |
1.6 / 2.0 / 2.5 / 3.2 / 3.8 / 101.6 |
|||||||||
