2.5mm OD Ceramic Sleeve for ST Fiber Connector

Specification:
Zirconia 2.5mm

Features:
 High quality ceramic material
 High performance and superior durability
 Low inse ion loss
 Design for ST Adapter and Attenuator
 Consistent withdrawal force
 Compliant with JIS Specification

Applications:
 Singlemode and Multimode
 Fiber Optic Receptacle, Adapter, Attenuator
 and other
 LD Receptacle

ITEM VALUES
Material Ceramic
Outer Diameter 3.2 ± 0.02 mm
Inner Diameter 2.49 mm
Length 10.1 ± 0.1 mm
Split Width 0.5 ± 0.1 mm
Chamfer 2 × R0.1
Pulling Force(N) 2 ~ 5.9
Specifications

Note:We also provide the copper connecter.

Zirconia 2.5mm
