Application
Key Features
200 Magnification, 0.75um Resolution Inspect 2-128 cores within fiber array on both PC/APC end face in one-time Real-time imaging without any delay Average spot between core and ceramic end face without any test error Fine tuning for image centralization No focus deviation, high efficiency for operation3 year warranty (1 year for display)
Order Information
| Model | FS-450-200/400FA | ||
| Item | 200X | 400X | |
| Inspection | Inspect 2-128 multiple fiber cores on both PC/APC end face without any clamp change | ||
| Accessory | Host 1pcs | ||
| 5-pin aviation connector 1pcs | |||
| 12V power supply 1pcs | |||
| 8 inch display 1pcs | |||
| FA (fiber array) clamp 1pcs | |||
| Display | 8 'LED | Φ39 | Φ73 |
| 9' CRT | Φ48 | Φ86 | |
| 10.4'LED | Φ49 | Φ90 | |
| Optional function | 1. USB function 2. 9 inch CRT display 3. 10.4 inch LEDdisplay | ||
Kind Note: This price is not include the display. If you need it, please contact us at sales@fiberinthebox.com without hesitation.
Specifications
| Magnification/Resolution | 200×/ 0.75μ 400×/ 0.5μ |
| Focus way | Manual |
| Size/Weight | 230×92×150mm 1.58kg |
| Useful life- Light Source | Coaxial blue LED with 80000 hrs working life |
| Useful life-Image Sensor | Image Sensor with 100000 hrs working life |
| Power Supply | 12V |
| Temperature/Humidity | -20-50℃ 99% |
| X/Y axis adjustment range | X axis：8mm Y axis：3.5mm |
| Connection Port | 5-Pin connector/BNC video output/USB function (optional) |
