Description
The Fluke Networks LinkRunner Duo Carrier Ethernet Tester provides quick network connectivity and cabling answers for the frontline technician working with copper or fiber. Features Link/PING Speed of 10/100/1000, does POTS/ISDN/Ethernet detection, cable wiremap, CDP/EDP/LLDP discovery protocols, Intellitone digital toning, PoE verification, 802.1X authentication & link status repo s.
Features
Verify Link Integrity and Signal Validate Provisioning Check Customer Equipment Use as a Reflector for Performance Testing Flexible Testing Approaches Designed for the Field
Features in Detail
Link Verification of Fiber and Copper Circuits at 10/100/1000MBps – Quickly determine if the circuit is up or not. Performance Testing with MetroScope and other Popular Test Sets – Use as a remote device for ProVision™, RFC 2544 and other performance tests with testers from Fluke Networks, JDSU, Sunrise, Exfo, and more. Layer 1, 2, and 3 Loopback - Configurable loop back to filter frame type and swap MAC and/or IP addresses. Manual or DHCP IP configuration. Fiber Power Measurements – Make sure that the incoming signal meets requirements. PING Testing – Measure availability and response performance for key devices or URLs.0 VLAN Verification - Configurable VLAN and priority settings. Designed for the Field – Small (fits in a shi pocket), lightweight (10oz), battery operated and rugged. Operates for over three hours with a removable Li-ion battery pack, four AA batteries, AC or optional car charger (optional). Document Results – Save link and ping test results and upload to a PC through the USB po . CPE Testing – Pinpoint problems on the customer side with po identification and 802.1x testing, cable and connectivity tests. Verify po settings and troubleshoot speed and duplex mismatch issues. Cable Testing – Test cabling and patch cords, including suppo for toning. Media Access - Copper: 10BASE-T, 100BASE-TX, 1000BASE-T (IEEE 802.3), Fiber (SFP): 100BASE-FX, 1000BASE-LX, SX, ZX, BX. Easy Upgrades – The mini-USB po on the LinkRunner Duo CE allows software upgrades in the field in jut minutes. And with our Gold suppo , you'll automatically receive upgrades at no additional charge. The LinkRunner Connect software also allows you to download repo s and capture screen graphics..
Family Comparison:
| Model Number/Name | Comparison Details (Accessories Description) |
| LRDUO | LRDuo LinkRunner Pro & Duo Network Multimeter: LinkRunner Duo, Wireview Cable ID #1, LinkRunner Connect Software CD, USB cable, RJ45 coupler, LinkRunner Duo getting sta ed guide, Four (4) AA alkaline batteries |
| LRPRO-1000 | LinkRunner Pro Network Multimeter: WireView Cable ID #1, LinkRunner Connect software CD, USB cable, LinkRunner Pro Getting Sta ed Guide (English, Spanish, French, German, Po uguese, Japanese, Simplified Chinese), four (4) AA alkaline batteries |
Picture details
Specifications
| General : | |
| Media Access | 10BASE-T, 100BASE-TX, 1000BASE-T (IEEE 802.3), and PoE (IEEE 802.3af) |
| Cable Tests | Pair lengths, opens, shorts, splits, crossed, straight through, and cable ID |
| Tone Generator | IntelliTone digital tone: [500 KHz]; analog tones: [400Hz, 1KHz] |
| Ports | Test ports: RJ45 ports; Application port: mini-USB |
| Power Source | 4 AA batteries |
| Weight | 10 oz (311 grams) with batteries installed |
| Dimensions | 5.3” h x 3.1” w x 1.3” d (13.46cm x 7.87cm x 3.30cm) |
| LinkRunner Connect Software | Operates on Windows XP and 2000; supports English, Spanish, French, German, Simplified Chinese, and Japanese |
| Warranty | One year |
| M12/ RJ45 Cable : | |
| Cable type | Ethernet cable, Cat5e, shielded, 2 pair AWG 26 stranded (7 wire), RAL 5021 (water blue), M12 4 pos. D- coded on RJ45 connector |
| Number of positions | 4 |
| Fixed cable length | 2 m |
| Volume resistance | ≤ 5 mΩ |
| Insulation resistance | ≥ 100 MΩ |
| Ambient temperature | -20 °C to 50 °C |
| Inflammability class acc to UL 94 | V0 |
| Surge voltage category | II |
| Pollution degree | 3 |
| Degree of protection | IP20/IP67 |
| External cable diameter | 6.7 mm |
| Transmission characteristics | Cat 5 (IEC 11801:2002), Cat 5e (TIA 568B:2001) |
