24 Fibers Single-mode Double-Jacket LSZH Loose Tube Cable

The price on the website is per meter price. The more, the cheaper.

The 24 Fibers Single-mode Double-Jacket LSZH Loose Tube Cables from Fiberinthebox are designed for industrial building backbones and harsh environments atypical of traditional datacom systems. With two durable LSZH jackets, these cables are ideal for applications requiring the added mechanical and environmental protection. Double Jacket combines flexibility with extra mechanical protection for a durable, reliable cabling solution that is easy to handle and install. Due to halogens in the jacket compound, these cables pose little risk in the controlled and protected environment of typical building air spaces, such as behind walls, under floors and in conduit. With LSZH compound, these cables do not drip when superheated, meanwhile the material burns to ash so it eliminates the risks in the event ofa fire in the industrial environment. The cables’ outstanding long-term performance and reliability begins with its field-proven loose tube design.

Features

Two Low-smoke/zero-halogen (LSZH) jackets deliver extra protection Proven loose tube design for performance Small diameter for ease of handling Lightweight, flexible, and easy to install, yet highly durable and reliable

Specification

Fiber Type	Singlemode
Fiber Core Diameter	8.2µm
Wavelengths	1310nm/1550nm
Fiber Count	24
Environment	Indoor/Outdoor Cables
Application	Aerial, Direct Buried, Duct, General Purpose Horizontal, Ve ical Riser
Cable Type	Loose Tube
Flame Rating	LSZH
Tight Buffer Color	Blue, Orange
Outer Jacket Color	Black
Max.Tensile Strengths,Sho -Term	4500N
Max.Tensile Strengths,Long-Term	1500N
Min. Bend Radius Installation	264mm
Min. Bend Radius Operation	176mm
Weight	299 kg/km
Storage Temperature	- 50°C to 75 °C
Installation Temperature	- 30°C to 60°C
Operation Temperature	- 50°C to 75 °C

Custom Information

Jacket Color: black, blue, orange, green, brown, slate, white, red, yellow, purple, rose, aqua or custom specified. Fiber Coloring: blue, orange, green, brown, slate, white, red, black, yellow, purple, rose, aqua or custom specified Fiber Count: Custom specified FiberType: Single-mode, Multimode Sheath Material: PE, PVC, LSZH or custom specified Cable Length: Custom specified
