48 Fibers Multimode Gel-Filled Loose Tube Outdoor Cable
The price on the website is per meter price. The more, the cheaper.
The 48 Fibers Multimode Gel-Filled Loose Tube Outdoor Cables from Fiberinthebox design provides stable performance over a wide temperature range and is compatible with any telecommunications-grade optical. The loose tubes contain optical fibers color coded as per color coding scheme.The cable protected by a black PE outer jacket, suitable for duct or aerial application. With the PE outer jacket, this cable is rugged, durable and easy to strip while providing superior protection against UV radiation, fungus, abrasion and other environmental factors.
Features
Small diameter & light weight, easy to routeExclusive Color-coded fibers, quick and easy identificationProper design, precise control for fiber excess length Easy handling Longer cable life
Specification
| Fiber Type | Multimode |
| Fiber Core Diameter | 50μm/62.5μm |
| Wavelengths | 850nm/1310nm |
| Fiber Count | 48 |
| Environment | Outdoor Cables |
| Application | Aerial, Duct |
| Cable Type | Loose Tube |
| Tape | Water-swellable |
| Outer Jacket Color | Black |
| Max. Tensile Strengths, Sho -Term | 2700N |
| Max. Tensile Strengths, Long-Term | 890N |
| Min. Bend Radius Installation | 158mm |
| Min. Bend Radius Operation | 105mm |
| Weight | 80kg/km |
| Cable Length | 1km |
| Storage Temperature | -40 °C to 70 °C |
| Installation Temperature | -30 °C to 70 °C |
| Operation Temperature | -40 °C to 70 °C |
Custom Information
Jacket Color: black, blue, orange, green, brown, slate, white, red, yellow, purple, rose, aqua or custom specified.Fiber Coloring: blue, orange, green, brown, slate, white, red, black, yellow, purple, rose, aqua or custom specifiedFiber Count: custom specified Fiber Type: Single-mode, Multimode Sheath Material: PE, PVC, LSZH or custom specified Cable Length: 1km, 2km, 5km, 10km, 30km or Custom specified
Specifications
| Fiber Type | Multimode |
| Fiber Core Diameter | 50μm/62.5μm |
| Wavelengths | 850nm/1310nm |
| Fiber Count | 48 |
| Environment | Outdoor Cables |
| Application | Aerial, Duct |
| Cable Type | Loose Tube |
| Tape | Water-swellable |
| Outer Jacket Color | Black |
| Max. Tensile Strengths, Short-Term | 2700N |
| Max. Tensile Strengths, Long-Term | 890N |
| Min. Bend Radius Installation | 158mm |
| Min. Bend Radius Operation | 105mm |
| Weight | 80kg/km |
| Cable Length | 1km |
| Storage Temperature | -40 °C to 70 °C |
| Installation Temperature | -30 °C to 70 °C |
| Operation Temperature | -40 °C to 70 °C |
