2 Fibers Multimode PVC Single-Jacket with Metal Strength member FTTH Drop Cable

The price on the website is per meter price. The more, the cheaper.

The 2 fibers FTTH Drop cables from Fiberinthebox with two parallel Metal strength members ensure good performance of crush resistance to protect the fiber. This cable is optical communication unit in the center so that it can realize the telephone, data, cable TV's combination of three nets and video monitoring. A steel wire as the additional strength member is also applied to ensure good performance of tensile strength. The PVC jacket with high Fire heat, enable the FTTH Drop cable can operate in high-temperature. Usually this cable is suitable for Indoor riser level and plenum level cable distribution and between instruments, communication equipments.

Features

Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission prope y. Novel flute design, easily strip and splice, simplify the installation and maintenance. Small diameter, water-resistant, soft and bendable. Single steel wire or massagers as the additional strength member ensures good performance of tensile strength Strong flame resistance, high mechanical strength an chemical prope ies, goog electrical insulation Longer cable life.

Specification

Fiber Type	Multimode
Fiber core diameter	50µm, 62.5µm
Wavelengths	850nm / 1300nm
Fiber Count	2
Environment	FTTH Drop Cables
Attenuation	≤3.5 dB/km(@850nm)
	≤1.5 dB/km(@1300nm)
Max. Tensile Strengths, Sho -Term	120N
Max. Tensile Strengths, Long-Term	60N
Max. Crush Resistance, Sho -Term	1000N
Max. Crush Resistance, Long-Term	300N
Static Bending Radius	15mm
Dynamic Bending Radius	30mm
Diameter(mm)	(2.0±0.2)×(5.4±0.2)
Sheath Material	PVC
Jacket Color	Black
Weight	26kg/km
Storage/Operating Temperature	-20 °C to +60 °C

Custom Information

Jacket Color: black, blue, orange, green, brown, slate, white, red, yellow, purple, rose, aqua or custom specified. Fiber Coloring: blue, orange, green, brown, slate, white, red, black, yellow, purple, rose, aqua or custom specified Fiber Count: 1 ~ 2 fibers or custom specified Fiber Type: Single-mode, Multimode Sheath Material: PE, PVC, LSZH or custom specified Cable Length: 1km, 2km, 5km, 10km, 30km or Custom specified
