16 Slots Dual Power Supply 19' 4U rack-mount chassis for 4V /8V /16V cards
The 16 Slots Dual Power Supply 19' 4U rack-mount chassis for 4V /8V /16V cards can akes your installation easier. The chassis employs a 220 VAC/48 VDC Switch Mode Power Supply(SMPS) design, which reduces the possibility of a single module failure causing a shutdown or a major failure of other modules within the chassis. The high reliability and stability ensures that if one module shuts down, the operation of the other modules remains unimpaired. 0ne or two air-cooling fans are installed inside to fu her strengthen the superior performance of the system and eliminate the necessity for periodic maintenance. Status information can be read through the LED indicators on the installed modules. All of the modules installed in the chassis are hot swappable, which makes it unnecessary to power-down.
Key Features
Panel material: Iron
It can suppo 16 pcs of 4 Channel Optic Video Multiplexer .
Standard:IEEE802.3 10/100 Base T Ethernet, IEEE802.3U, 100Base V TX/FX Fast Ethernet, IEEE802.3 x Flow control, IEEE802.3.1q VLAN, IEEE802.1p QoS, IEEE802.1d Spanning Tree
Power configuration: Dual power supply for warm backup mode
Hot Swap Suppo for the Multiplexers to ensure a flexible connection
Equipped with a second, redundant Power Supply for maximum stability and reliability
It can suppo 16 pcs of 4 Channel Optic Video Multiplexer .
Standard:IEEE802.3 10/100 Base T Ethernet, IEEE802.3U, 100Base V TX/FX Fast Ethernet, IEEE802.3 x Flow control, IEEE802.3.1q VLAN, IEEE802.1p QoS, IEEE802.1d Spanning Tree
Power configuration: Dual power supply for warm backup mode
Hot Swap Suppo for the Multiplexers to ensure a flexible connection
Equipped with a second, redundant Power Supply for maximum stability and reliability
Applications
Numberof slots: 16
Video Multiplexers adapted: 16 slots chassis card-type video multiplexers
Power in: AC 100 V~260 V, 50~60Hz ; OR DC 48V
Power out: DC + 5V ,24A(dual power)
Diameter of DC plug: 2.5/5.5 mm
Pipple:≤50Mv
Noise:≤50 Mv
Protection of power supply: circuit-breaker when over voltage; circuit-breaker when over flow; circuit-breaker when sho circuit
Operating Temperature: 0°C~50°C
StorageTemperature: 0°C~85°C
Relative Humidity: 5%~95%
Dimensions: L485, W231, H90 mm; 19 inches 4U
Video Multiplexers adapted: 16 slots chassis card-type video multiplexers
Power in: AC 100 V~260 V, 50~60Hz ; OR DC 48V
Power out: DC + 5V ,24A(dual power)
Diameter of DC plug: 2.5/5.5 mm
Pipple:≤50Mv
Noise:≤50 Mv
Protection of power supply: circuit-breaker when over voltage; circuit-breaker when over flow; circuit-breaker when sho circuit
Operating Temperature: 0°C~50°C
StorageTemperature: 0°C~85°C
Relative Humidity: 5%~95%
Dimensions: L485, W231, H90 mm; 19 inches 4U
