Power Meter AOP100 series can provide precision measurement from 850 to 1625nm wavelength ranges and measuring range including -70dBm to +10dBm, -50dBm to +26dBm. Optical power meter can test the PM power to the light, light stability, inse ion loss, optical transmittance, reflectance of light and so on. It widely used in optical fiber communications, Fiber Optical Sensors etc. It is indispensable for scientific research and engineering construction.
APM820: +10 ~ -70 dBm,
APM830: +26 ~ -50 dBm,
reference value set.
Test the loss of the fiber
| AOP100T | AOP100C | |
| Measuring Range | +10~-70dBm | +26~-50dBm |
| Calibrated Wavelengths | 850/1300/1310/1490/1550/1625nm | |
| Display Resolving Power | 0.01dB | |
| Connecting Adaptor | FC (2.5mm universal adapter) | |
| Accuracy | ±0.2dB | |
| Reference Value Set | Yes | |
| Auto Power Off | About 10 minutes(can be cancelled) | |
| Battery Charge | Yes | |
| Data Storage | Yes | |
| Size | 140mm*62mm*31mm | |
| Weight | About 150g | |
Fiberinthebox is specializing in supplying optical fiber components and network equipment, all the products are qualified because they have been 100% tested before delivery, especially the optical power meter. And a special discount will be provided if you need this brand new Optical Power Meter AOP100C at a large quantity.
