10/100M 1SFP+1RJ45 Po s Ethernet Fiber Media Conve er
Media conve ers can be used anywhere in the network to integrate newer technology with existing equipment to suppo new applications, technologies and future growth. Instead of costly, across-the-board upgrades, media conve ers can extend the productive life of the existing cabling as well as the active equipment.
Fiberinthebox.COM supply 10/100Base Ethernet Fiber Media Conve ers, 1000Base Gigabit Fiber Media Conve er,SFP Fiber Media Conve er, Options in singlemode dual fiber, multimode dual fiber and singlemode single fiber. We also supply Media Cove er Chassis, like 14 slot media conve er chassis and 16 slot media conve er chassis, used to manage the various media conve ers.
Features
AutoCross™: Automatically detects and configures the twisted pair po on the conve er to the correct MDI or MDI-X configuration. Link Pass Through: Link Pass Through is a troubleshooting feature that allows the media conve er to monitor both the fiber and copper RX po s for loss of signal. Automatic Link Restoration: The media conve ers will automatically re-establish link in all network conditions. Selectable speed setting: The conve er can be set to 10Mbps or 100Mbps. Both copper and fiber po s are automatically set to the same speed. Devices connect to duplex mode of link pa ner.
Key Features
One RJ45 po s and one SFP sockets ,It can conve Optical-Electric Ethernet signals between 10/100/1000M UTP po s and 1000M optical fiber po s and switch Ethernet signals between po and po .Auto negotiation function suppo s UTP po s to auto 10/100/1000M and Full Duplex/Half Duplex. Broadcast storm protection Suppo s VLAN and QoS Suppo s the max 1536 bytes frame Small power consumption (3W), low heat, good stabilit
Applications:
Extend Ethernet Network Distances
It use the 10BASE-T to 10BASE-FL speed setting (back-to-back) to extend the distance between two 10BASE-T devices up to 100km. using single mode fiber without a repeater.
Extend Fast Ethernet Network Distances
It use the 100BASE-TX to 100BASE-FX setting to extend the distance between any two 100BASE-TX devices up to 100km. using single mode fiber. Or interface directly with a 100BASE-FX compliant po on any device to provide a 100BASE-TX po interface.
Specifications
Operating standards: IEEE802.3z/AB, 10/100/1000Base-T and 1000Base-SX/LX MAC address: 1K Frame buffer memory: 512Kb RAM UTP cable: Cat. 5 (the max distance up to 100m) Multimode Fiber: 50/125, 62.5/125μm(the max distance up to 224/550m) Single-mode Fiber: 8/125, 8.7/125, 9/125, 10/125μm (the max distance up to 100km) Flow control: Full Duplex: IEEE802.3x flow control; Half Duplex: bake pressure flow control Power: AC100 ~ 240V, 50~60Hz; DC5V 2A; Operating Temperature: 0℃~+50℃ StorageTemperature: -20℃~+85℃ Relative Humidity: 5%~95%Dimension (mm): 26*70*95 （with external power), 30*110*140 (with built-in power)
Note: This picture is 2SFP+4RJ45 media conve er, pls use this picture for your reference.
