E1 to Ethernet 10/100Base-T conve er provides easy conversion from ITU-T G.703 E1 channel to Ethernet interface. Can used widely in connecting between WAN and LAN, monitoring, etc. The Ethernet interface is 10/100Mbps auto negotiation and can be full/half duplex.
Features:
- High performance bridge for 10(100) Base-T Ethernet extension
- Fully compatible with IEEE 802.3 and Ethernet Standards
- E1 channel: both framed & unframed
- 75 & 120 Ohm impedance
- Ethernet Po : 10 Mbps, Full/Half Duplex Mode compatible
- Ethernet po s suppo MDI/MDI-X selectable
- Allow transmitting and receiving VLAN data packet
- 15000 frames per second filtering and forwarding rate
- 1000 MAC address LAN table, and automatic LAN table learning and aging
- Standalone and Module optional
- Power of Chassis: 2 slots for slide in power supplier module, AC or DC power supplier module, redundant power suppo ed
- AC 220 V±20% or DC -48 V power input
Specifications:
LAN po
- Standard: Conforms to IEEE802.3 / 10(100) Base-T Ethernet
- Data rate: 10 Mbps (20 Mbps/10 Base-T in Full duplex topology)
- Compatible on Full/Half duplex topology
- Connectors: RJ-45 connector
- Transfer distance: <150 m
E1 po
- Standard: ITU G.703, G.704,
- Jitter Performance: According to ITU G.823
- Bit rate: N×64 Kbps, N=1~31 (Fractional Mode) or 2.048 Mbps (Full Mode)
- Line Code: HDB3
- Line Impedance: 75/120 ohms optional
- Pulse Amplitude: Nominal 2.37 V±10%
General:
- Voltage: AC 220 V ±20% or DC -48 V optional
- Power Consumption: <3 Watts
- Temperature: 0-50℃
- Humidity: 0-90%(non-condensing)
- Size(Width×Deep×High): 230 mm ×124 mm× 36 mm
