Description
Optical power +5 km red + Lithium + USB Charging + Data + real-time clock management software + save + user-calibration +...
5km red light power meter combined
New User calibration function
Multi-wavelength precision measurement
Relative power measurement dB
With real-time clock feature, you can display the current time. Recording time available for storing data
255 groups of test data storage
Ergonomic handheld design, graphic dot matrix LCD display, easy to use
LED-backlit display
Optional switch backlight display, auto backlight off 60 seconds off the backlight automatically
|
SPECIFICATION |
|
|
Model |
TL503B |
|
Wavelength(nm) |
800-1600nm |
|
Detector type |
InGaAs |
|
Measurement Range (dBm) |
-50~+20dBm |
|
Unce ainty (dB) |
±5% |
|
Calibrated Wavelength(nm) |
850, 980, 1300, 1310, 1490, 1550 |
|
Display resolution(dB) |
0.01 |
|
Optical Connector |
FC(Interchangeable SC,ST)/As well as 2.5mm universal |
|
Battery Operating time (h) |
260 h |
|
Operation Temperature(℃) |
-20℃~+70℃ |
|
Storage Temperature(℃) |
-30℃~+80℃ |
|
Shut down(min) |
3 min |
|
Dimension(mm) |
175*79*46(mm) |
|
Power Supply |
3.7V1600mAh |
|
Weight(kg) |
0.26 |
Note: We provide FC, ST, SC Connector for choose. If no special requirement, we will send you the FC connector.
If you need more than one connector, please contact our sales at sales@fiberinthebox.com for more details because the price would be different.
Fiberinthebox is your reliable supplier of optical power meter, all the products are 100% tested before delivery. If you need this brand new TL503B optical power meter with 5km red light at a large quantity, please feel free to contact us. We will provide you a special discount.
|
SPECIFICATION |
|
|
Model |
TL503B |
|
Wavelength(nm) |
800-1600nm |
|
Detector type |
InGaAs |
|
Measurement Range (dBm) |
-50~+20dBm |
|
Uncertainty (dB) |
±5% |
|
Calibrated Wavelength(nm) |
850, 980, 1300, 1310, 1490, 1550 |
|
Display resolution(dB) |
0.01 |
|
Optical Connector |
FC(Interchangeable SC,ST)/As well as 2.5mm universal |
|
Battery Operating time (h) |
260 h |
|
Operation Temperature(℃) |
-20℃~+70℃ |
|
Storage Temperature(℃) |
-30℃~+80℃ |
|
Shut down(min) |
3 min |
|
Dimension(mm) |
175*79*46(mm) |
|
Power Supply |
3.7V1600mAh |
|
Weight(kg) |
0.26 |
