Description
The NF-8208 multipurpose network cable test & inspection instrument is composed of tester (NF-8208), receiver (NF-838-R) and remote identifier. The new instrument is provided with fluent appearance, excellent hand feel and considerate human-centered design. It owns three great functions: hunting, wire so ing and circuit status testing with reliable accuracy, so it is widely applicable to telephone system, computer network, other metal wire circuit and other fields. It is really a kind of available tool for technicians in installation and maintenance of weak current system such as communication line, comprehensive wiring circuit, etc.
Features
1. One person enough to complete cable continuity check.
2. The function of probing the audio and tracing the cable.
3. Check wiring error in 5E, 6E, telephone line, coaxial cable, such as open circuit, sho circuit, jumper wire, reverse connection or cross-talk interference.
4. Locate the wiring or connection error.
5. Measure cable length and determine the distance f open circuit and sho circuit.
6. Dynamically calibrate cable length and make length measurement as accurate as 97%.
7. Simple and use. Big screen to display test result clear.
8. Po able unit with long battery life ( wait-case 50 hours)
9. Automatically time-delay shut off.
10. Measure length and pair with or without far-end recognizer.
11. Locate cable and there are 8 far-end passive test jacks (ID No.ID1-ID8).
12. Far-end recognizer with prompting voice.
13. Self-checking function and automatically compensate and change in battery capacity or ambient temperature.
14. Single board computer software watchdog design and reliable operation.
2. The function of probing the audio and tracing the cable.
3. Check wiring error in 5E, 6E, telephone line, coaxial cable, such as open circuit, sho circuit, jumper wire, reverse connection or cross-talk interference.
4. Locate the wiring or connection error.
5. Measure cable length and determine the distance f open circuit and sho circuit.
6. Dynamically calibrate cable length and make length measurement as accurate as 97%.
7. Simple and use. Big screen to display test result clear.
8. Po able unit with long battery life ( wait-case 50 hours)
9. Automatically time-delay shut off.
10. Measure length and pair with or without far-end recognizer.
11. Locate cable and there are 8 far-end passive test jacks (ID No.ID1-ID8).
12. Far-end recognizer with prompting voice.
13. Self-checking function and automatically compensate and change in battery capacity or ambient temperature.
14. Single board computer software watchdog design and reliable operation.
Technical Indexes:
| Overall dimension | Main tester: 180×80×40mm; receiver: 218×46×29mm;Remote identifier: 77×31×21mm. |
| Power | Main tester: 6V DC battery. Receiver: 9V DC battery. |
| Display | Special 4 x 16 character big screen LCD lattice (valid visual field 61.6 x 25.2 mm). |
| tested cables | STP/UTP twin twisted cable, coaxial cable, telephone line. |
| detected lines | 5E, 6E, telephone wire, coaxial cable and other metal wires. |
| Ambient temperature of work | -10℃~+60℃ |
| Tester Po | Tester RJ45 master po (M), tester LOOPBACK RJ45 po (L), hunting RJ45 po (SCAN); Remote identifierRJ45 po (R); The extra BNC and RJ11 conve ers (to measure and check the continuity of coaxial cable and telephone line). |
| Length Measurement of Twin Twisted Cable | Scope: 1~350 M (3 ~200 ft) |
| Calibration accuracy: 3% (+/- 0.5M or +/- 1.5 ft) (calibrating cable > 5 M) | |
| Shipment accuracy: 5% (+/- 0.5 M or +/- 1.5 ft). (AMP, AT&T Class 5 cable) | |
| Length Calibration | User can set calibration factor by himself with a given length cable. The length of cable is more than 5M. |
Package Including
- 1 x Main Tester (Emitter)
- 1 x Receiver
- 1 x Recognizer (Remote Identifier)
- 1 x RJ45 cable (12.5cm length)
- 1 x RJ11 to Alligator Clip conve er
- 1 x 3.5mm earphone (100cm length)
- 1 x Carrying pouch
- 1 x User Manual
- 1x Colored Packaging Box
Generally speaking, a network cable tester is a device that test for different types of faults in cables like continuity, dislocation, open circuit, sho circuit, cable pairing faults, or indications like shielding indication, straight cable/ cross over cable indication, etc. We Fiberinthebox.com provide various types of this product, from basic to complicated, and all of high quality and good price. If you need this NF-8208 Communication Cable/Wire Tone Tracker in a large quantity, we will provide you a special discount.
- 1 x Receiver
- 1 x Recognizer (Remote Identifier)
- 1 x RJ45 cable (12.5cm length)
- 1 x RJ11 to Alligator Clip conve er
- 1 x 3.5mm earphone (100cm length)
- 1 x Carrying pouch
- 1 x User Manual
- 1x Colored Packaging Box
Detailed Picture
