LCD Wire and Cable Tester Scanner SML-8828
Key Features
Can check error such as open, sho circuit, jumper, reverse, crossover matching connections for 5E/6E network cable, BNC cable, USB and phone line and visually displays on the LCD To test crosstalk error on cable to shut out the potential issue of slow network speed Super searching-lines feature make you find the cable, telephone lines and other various metal wires among the numerous lines, help to find the line what you want at another remote end by the size of the prompt volume, with anti-interference and high sensitivity, the volume control knob on receiver can be adjusted for sensitivity Can accurately determine the exact open point in the crystal end of cable (left, right or middle) Automatically shut-off while time-delay With a low voltage display when voltage is lowWith a self-test and adjust functions to various conditions such as the automatic replenishment for battery capacity and ambient temperature while it changes
Warnings
The tester uses a stacked battery 9V power The tester will shut off automatically if it does not work for 15 minutes LCD display low battery when this battery with too low voltage and influence its operation , this series inspectors are developed for testing different cable terminals, they cannot be misused, otherwise they will be damaged permanently
Specification
Display: dot 128x64 Sequence LCD lattice (valid visual field 48x32mm) Power Supply: stacked Battery of 9V with power consumption 15 mA Low battery display: The 9V battery voltage is lower than 6.5 V, LCD displays low batteryDimension: 149x 66x23 mmType of Test Cable:STP/UTP twisted cable, Coaxial cable, telephone line, USB line, wire line by alligator clip.Tester Po :Tester RJ45 master po (M), tester Loopback RJ45 po (S), BNC, USB (A), RJ11, far-end recognizer RJ45 po (R), The extra BNC, US(B) and RJ11 conve ers are used to measure and check the continuity of coaxial cable , telephone line and USB lineWorking Ambient Temperature:-10℃------+60℃Wire Sequence and Locating Cable Error:Check errors such as open circuit, sho circuit, reverse connection, crossover or cross-talk, interference.Locating cable: 8 far-end passive test jacks (ID 1 > ID8)Automatic time-delay Shut off Time:The tester does not operate for15 minutesScanning and Locating Wiring 5E, 6E, Coaxial cable, USB line and telephone lineThe sensitivity is changed by adjust the volume switch
Specifications
Display: dot 128x64 Sequence LCD lattice (valid visual field 48x32mm) Power Supply: stacked Battery of 9V with power consumption 15 mA Low battery display: The 9V battery voltage is lower than 6.5 V, LCD displays low batteryDimension: 149x 66x23 mmType of Test Cable:STP/UTP twisted cable, Coaxial cable, telephone line, USB line, wire line by alligator clip.Tester Port:Tester RJ45 master port(M), tester Loopback RJ45 port(S), BNC, USB (A), RJ11, far-end recognizer RJ45 port(R), The extra BNC, US(B) and RJ11 converters are used to measure and check the continuity of coaxial cable , telephone line and USB lineWorking Ambient Temperature:-10℃------+60℃Wire Sequence and Locating Cable Error:Check errors such as open circuit, short circuit, reverse connection, crossover or cross-talk, interference.Locating cable: 8 far-end passive test jacks (ID 1 > ID8)Automatic time-delay Shut off Time:The tester does not operate for15 minutesScanning and Locating Wiring 5E, 6E, Coaxial cable, USB line and telephone lineThe sensitivity is changed by adjust the volume switch
