SHOMLIN LCD Network Cable Tester SML-8838
It is a tool to test the cat.5e, cat6e, UTP, STP cable and the coaxial cable as well as the telephone wire, tec. It can also test the the situations like the breaking at the set point, the sho circuits, the Gross pair wire, and the split pairs as well the reversed pair wire,etc.
Key Features
With M-S and M-R two methods to check error such as open, sho circuit, jumper, reverse, crossover, matching connections and cable break point for 5E/6E cable, BNC cable, USB and phone line and visually displays on the LCD To test crosstalk error on cable to shut out the potential issue of slow network speed With the M-S, M-R, OPEN three methods to measure the cable length up to 1,200 meters for network cable, coaxial cable, telephone line, USB cable. The accuracy of the measurement of length and location of cable break point is up to 98%. Can determine which side is open between two cables ends tested, and accurately determine the exact open point in the cable end (left, right or middle) With a low voltage display when voltage is low Automatically shut-off while time-delay With a self-test and adjust functions to various conditions Can test the connection between network cable and router is good or not, and router can be live tested
Applications
RJ45 network cable,RJ11 telephone line, BNC coaxial cable It can test or scan other type of cable via alligator adapter
Functions
Check various circuit status in cable by wire map Judge the connection status of cableJudge the open point in crystal po of cableCheck the crosstalk in cable po , crosstalk will leads to a slow network speed Measure the length of various cable
Warning
The cable tester will automatically shut off if not work for 15 minutes It prompts“low battery” and can’t work normally while the battery voltage is lowUsed for: RJ45 cable, RJ11 telephone line, BNC coaxial cable, test other wire line via alligator clip (an adapter) Can’t be used to test charging cables working with power, a misuse will lead to permanent damage for it
