Description
The JDSU MTS-4000 OTDR is a small, compact and handheld test platform designed for all phases of the network lifecycle, from the installation to the maintenance of Access / FTTx networks and triple-play services. Modular in design, the MTS-4000 offers field service technicians the highest performance and superior levels of scalability and upgradeability.
Highlights:
Key Features:
• Optimized for access/FTTx networks
• Tests up to three wavelengths in one module
• 32/30 dB Dynamic Range at 1310/1550 nm
• High resolution and sho dead zone for distribution fiber qualification
• Automatic traffic detection
• Source and power meter through OTDR po (optional)
• In-service testing dedicated wavelengths (1625 or 1650 nm)
• Automatic macro-bend detection
• Field-replaceable without tools
• Can be combined with PON Power Meter Module in the same T-BERD/MTS-4000 unit
• Up to 128,000 acquisition points with sampling resolution down to 4 cm
• Comprehensive suite of PC software tools for post-processing of test results, including FiberTrace (OFS-100) and FiberCable (OFS-200)
Applications:
Family Comparison
| Module | Central wavelength | Pulse width | RMS dynamic range | Event dead zone | Attenuation dead zone |
| E4126LA | 1310/1550±20 nm | 3 ns to 10 μs | 34/32dB | 1 m | 4 m |
| E4126MAE | 1310/1550±20 nm | 3 ns to 20 μs | 40/38dB | <1 m | 4.2 m |
Design Efficiency
Note: This price is only for module E4126LA with standard accessories, and we can also provide E4126MA. If you are interested in this, please feel free to contact me.
Fiberinthebox is specializing in supplying optical fiber components and network equipment, and we are trying to complete this system. For the OTDR, we provide one year warranty for each domestic and foreign brand product. If you have any problems or special requirement of this JDSU MTS-4000 OTDR, please feel free to contact us. We will try our best to provide you the best service.
| Technical (Typical at 25°C) | ||
| Display | TFT color, 7-in, LCD 800*480,high visibility for outdoors touch screen (12.5cm) | |
| Touchscreen, TFT color,7-in, LCD 800*480, high visibility for outdoors | ||
| Storage and I/O Interfaces | Internal memory | 32MB (1000 test results) |
| Extended memory (optional) | Minimum 1GB (optional） | |
| 2* USB2.0, 1* RJ45 Ethernet (up to 1Gbps) | ||
| WIFI | Standard IEEE 802.11 b/g | |
| Blurtooth | Class 2, up to 10 m range | |
| Audio interface | 2.5 mm jack connector | |
| Ethernet | 10/ 100/ 1000 MHz fully-half duplex | |
| Power supply | Battery type | Standard removable Li lon batteries |
| AC/DC adapter | Input 100-250V, 50-60 Hz | |
| Output 12-15V DC/3.7A | ||
| Electrical safety | EN 60950 Compaliant | |
| Operation time | Up to 11 hours with standard display Telcordia GR-196-CORE | |
| Size and Weight | Mainframe with two modules and battery (W*H*D) | 260*135*90mm (10.2*5.3*3.5 in) |
| Mainframe only ( with battery | 1.4 kg (3 lb) | |
| Mainframe with one module (with battery) | ﹤2 kg (﹤4.35 lb) | |
| Environmental | Operating temperature range (no option) | -20°C~+50°C (-4°F~+122°F) |
| Operating temperature range (all options) | 0 ~ + 40°C （32 °F~104°F | |
| Storage temperature range | -20°C~+60°C (-4°F~+140°F) | |
| Humidity, non-condensing | 95% | |
