Features
1. TDR: can test the line break, line mix, poor insulation etc
2. Faults waveform display: Convenient, intuitively clear interface –
3. Accurate and quick auto test
4. Friendly man-machine interface, easy operation
5. Dry battery/ rechargeable batteries for power supply; east to change; Auto-off when low battery voltage; auto-off when there’s no operation for seconds
6. Handheld and easy to carry
Specifications
1. Measurement range: 0-8km
2. Resolution: max 1m(0-125m); max 2m( 125m-250m); max 4m ( 250m-500m); max 8m ( 500m-1km);
max 16m(1km-2km);max 32m( 2km-4km); max 64m (4km-8km).
3. Pulse amplitude: 30V
4. Pulse Width: 80ns-5μs;
5. Dead zone: 1m
6. Velocity adjustment range: 100-300m/μs
7. Gain adjustment range: 0-80dB
8. Display: 128*64 lattice LCD
9. Power Supply: 6*5aa batteries or Ni-MH battery
Note: This model (TL250 Tel Cable Fault Locator) is going to stop production, but do not worry, we can provide another model for subtitution. Any requirement, please free to contact us.
