FS108B ADSL2+ Tester is an ideal tool for ADSL/ADSL2+ network installation, maintenance and faults elimination. It is simple, efficient, reliable and economic. Fixing & maintenance staff’s best choice!
Functions
DSL Physical layer test
Modem Emulation (Replace the user Modem completely)
PPPoE dial
DMM Test, FS108B not has this function, FS108 includes DMM Test
Ping Function (WAN & LAN)
Data memory capacity: 100 records
Data upload to computer by RS232 core and software management
Print test record through PC via management software
Setup system parameter: shut off automatically time without operation, press tone, revise PPPoE dial attribute, user name and password, set VPI.VCI pamameter.
Check dangerous voltage.
Set physical parameters alarm threshold, View every parameter alarm status.
Digital keyboard input
|
SPECIFICATIONS |
|
|
ADSL2+ |
|
|
Standards |
ITU G.992.1(G.dmt), ITU G.992.2(G.lite), ITU G.994.1(G.hs), ANSI T1.413 issue #2, ITU G.992.5(ADSL2+)Annex L |
|
Up channel rate |
0~1.2Mbps |
|
Down channel rate |
0~24Mbps |
|
Up/Down attenuation |
0~63.5dB |
|
Up/Down noise margin |
0~32dB |
|
Output power |
0~31.5dBm |
|
Error test |
CRC, FEC, HEC, NCD, LOS |
|
Display DSL connect mode |
Available |
|
Display channel bit map |
Available |
|
ADSL |
|
|
Standards |
ITU G.992.1 (G.dmt) ITU G.992.2(G.lite) ITU G.994.1(G.hs) ANSI T1.413 Issue # 2 |
|
Up channel rate |
0~1Mbps |
|
Down channel rate |
0~8Mbps |
|
Up/Down attenuation |
0~63.5dB |
|
Up/Down noise margin |
0~32dB |
|
Output power |
0~31.5dBm |
|
Error test |
CRC, FEC, HEC, NCD, LOS |
|
Display DSL connect mode |
Available |
|
Display channel bit map |
Available |
|
DMM Test |
|
|
DC Voltage |
0 to 400 V |
|
AC Voltage |
0 to 290 V |
|
Capacitance |
0 to 1000nF |
|
Loop Resistance |
0 to 20KΩ |
|
Insulation Resistance |
0 to 50MΩ |
|
General Specification |
|
|
Power supply |
Internal Rechargeable 2000mAH Li-ion battery |
|
Battery Duration |
4 to 5 hours |
|
Working temperature |
10-50 |
|
Working moisture |
5%-90% |
|
Dimensions |
201mm×92mm×36mm |
|
Weight |
<0.5kg |
The ADSL Tester suppo s the testing function such as parameter, error, DMM, PING that related to ADSL2+ service, it can directly enables the engineers to verify, troubleshoot and evaluate the ADSL2+ service. For all our products of this kind, we provide one year warranty for that. If you need this high performance FS108B ADSL2+ Tester / FS108B ADSL Tester, welcome to contact us.
|
SPECIFICATIONS |
|
|
ADSL2+ |
|
|
Standards |
ITU G.992.1(G.dmt), ITU G.992.2(G.lite), ITU G.994.1(G.hs), ANSI T1.413 issue #2, ITU G.992.5(ADSL2+)Annex L |
|
Up channel rate |
0~1.2Mbps |
|
Down channel rate |
0~24Mbps |
|
Up/Down attenuation |
0~63.5dB |
|
Up/Down noise margin |
0~32dB |
|
Output power |
0~31.5dBm |
|
Error test |
CRC, FEC, HEC, NCD, LOS |
|
Display DSL connect mode |
Available |
|
Display channel bit map |
Available |
|
ADSL |
|
|
Standards |
ITU G.992.1 (G.dmt) ITU G.992.2(G.lite) ITU G.994.1(G.hs) ANSI T1.413 Issue # 2 |
|
Up channel rate |
0~1Mbps |
|
Down channel rate |
0~8Mbps |
|
Up/Down attenuation |
0~63.5dB |
|
Up/Down noise margin |
0~32dB |
|
Output power |
0~31.5dBm |
|
Error test |
CRC, FEC, HEC, NCD, LOS |
|
Display DSL connect mode |
Available |
|
Display channel bit map |
Available |
|
DMM Test |
|
|
DC Voltage |
0 to 400 V |
|
AC Voltage |
0 to 290 V |
|
Capacitance |
0 to 1000nF |
|
Loop Resistance |
0 to 20KΩ |
|
Insulation Resistance |
0 to 50MΩ |
|
General |
|
|
Power supply |
Internal Rechargeable 2000mAH Li-ion battery |
|
Battery Duration |
4 to 5 hours |
|
Working temperature |
10-50 |
|
Working moisture |
5%-90% |
|
Dimensions |
201mm×92mm×36mm |
|
Weight |
<0.5kg |
