More accurate testing result and better repeatability
Up to 8 fiber faults can be detected in each measurement
Automatic Pulse Width Control design to ensure a convenient operation
Easy to identify the faults location
Built-in visual fault locator (VFL), conveniently to find the faults in dead zone
Dust, water and shock proof, designed for field use
Long battery life, up to 5000 measurements operation
Locates reflective and non-reflective breaks in the fiber network
Inspection of fiber repair and maintenance
Fiberinthebox is specializing in supplying optical fiber components and network equipment, and we are trying to complete this system. For the JW3304N Optical Fiber Ranger, we provide one year warranty for each domestic and foreign brand product. If you have any problems or special requirement of this kind of optical fiber ranger, please feel free to contact us. We will try our best to provide you the best service.
|
SPECIFICATIONS |
||
|
MODEL |
JW3304N |
|
|
Operating Wavelength |
1550nm (1310nm optional) |
|
|
Fiber Type |
9/125um SM Fiber |
|
|
Optical Connector Type |
FC/PC |
|
|
Detector Type |
InGaAs |
|
|
Peak Power of laser |
≥60mW |
|
|
Max. Displaying Distance |
Reflection Event |
60km (≥1dB) |
|
Non-reflection Event |
20km (≥2.5dB) |
|
|
Measurement Unit |
m |
|
|
Reflection Event Dead Zone |
15m |
|
|
Distance Accuracy (Reflection Event) |
± (2m+2*10 (-3)*Distance) |
|
|
Wavelength of VFL Option |
650nm |
|
|
Output Power of VFL Option |
≥1mW |
|
|
Power Supply |
Alkaline Battery (3pcs AA 4.5V Batteries) |
|
|
Battery Operating Time |
≥5000 measurements |
|
|
Working Temperature |
-5~40℃ |
|
|
Storage Temperature |
-10~60℃ |
|
|
Humidity |
0~85% (Non-condensation) |
|
|
Dimensions |
190*100*50mm |
|
|
Weight (g) |
450 |
|
