Portable Optical Time-domain Reflectometer (OTDR) WF20A

Description

WF20A handhold Optical Time Domain Reflector (OTDR) is a high performance, cost-effective optical network analysis tester, with the feature of lightweight, easy to use, highly intelligent and having a hotkey for automatic rapid testing.

WF20A handhold OTDR is small, powerful and po able. It is battery powered. 3.5 Inch TFT-LCD can meet the needs of high luminance environment and night. WF20A OTDR has simple and friendly graphical user interface. Touch screen panel and keyboard button can meet different operator’s habits.

Hotkey for rapid testing, and just press the hotkey you can obtain the required operational test results. WF20A OTDR provides three power saving modes, Close the LCD screen, equipment sleep and power-down ,for users to select according different applications, to ensure that the equipment to achieve a longer working hours.

Features:

1310/1550 dual-wavelength testing;

Visible light source, facilitate to inspect fiber break;

Complete PC analysis software for you to quickly and efficiently generate a professional OTDR repo s;

Easy to operate, both the touch-screen panel and keyboard button can completely operate the equipment, meeting different operator’s habits;

All impo ant tests can provide a hotkey to operate automatically, to ensure higher test efficiency;

3.5-inch TFT LCD with brightness adjustment suppo , suit for high luminance environment and night;

With auto-sleep function to save power;

NI-MH battery-powered, low-voltage protection, continuous working time up to 8 hours;

Hardware power switch, thorough stop electrical energy loss, ensures the battery can work longer;

Main Functions:

Determine optical fiber cable or optical fiber’s failure point, connection point, breakpoint position

Describe optical fiber cable or fiber’s loss distribution curve, measure cable, fiber’s length and the loss, attenuation coefficient between two points

Measure optical fiber cable, optical fiber connector’s inse ion loss

Measure optical fiber cable, optical fiber’s reflection loss;

WF20A handhold OTDR can be widely used in metropolitan, WAN, CATV and other communication systems for optical fiber cable or fiber installation, troubleshoot, transformation and maintenance.

Specification:

:
